Capacidad
- Capacidad (Enfriamiento, Btu/hr)16889 Btu/hr
- Capacidad (Calefacción, Btu/hr)17913 Btu/hr
- Capacidad (Enfriamiento, kW)4.95 kW
- Capacidad (Calefacción, kW)5.25 kW
- Capacity (Cooling, Min - Max, kW)1.992 ~ 6.125 kW
- Capacity (Heating, Min - Max, kW)1.056 ~ 6.745 kW
Eficiencia energética
- EER (Cooling, W/W)3.21 W/W
- COP (Heating, W/W)3.41 W/W
- EER (Cooling, Btu/hW)10.95 Btu/hW
- COP (Heating, Btu/hW)11.63 Btu/hW
- Energy Efficiency Class for cooling (Grade)A
Ruido
- Noise Level (Indoor, High/Low, dBA)44/36.5/32.5 dBA
- Noise Level (Outdoor, High/Low, dBA)57 dBA
Información eléctrica
- Alimentación (Φ/V/Hz)1 / 220 - 240 / 50
- Consumo de energía (Enfriamiento, W)1542 W
- Consumo de energía (Calefacción, W)1540 W
- Corriente de operación (Enfriamiento, A)7.15 A
- Corriente de operación (Calefacción, A)7.14 A
Especificaciones físicas
- Gross Dimension (Indoor, WxHxD, ㎜*㎜*㎜)1,045 x 405 x 305 mm
- Gross Dimension (Outdoor, WxHxD, ㎜*㎜*㎜)915 x 615 x 370 mm
- Netas (Unidad interna, WxHxD, ㎜*㎜*㎜)971 x 321 x 228 mm
- Netas (Unidad exterior, WxHxD, ㎜*㎜*㎜)805 x 554 x 330 mm
- Gross Weight (Indoor, kg)16.6 kg
- Gross Weight (Outdoor, kg)35.1 kg
- Net Weight (Indoor, kg)12.5 kg
- Net Weight (Outdoor, kg)32.2 kg
- Loading Quantity (20/40/40Hft without Pipe)154
Información técnica
- Piping Length (Max, m)30.0 m
- Piping Height (Max, m)20.0 m
- SVC Valve (Liquid (ODxL))6.35
- SVC Valve (Gas (ODxL))12.7
- Moisture Removal (l/hr)1.70 l/hr
- Air Circulation (Cooling, ㎥/min)740 ㎥/min
- Refrigerant (Type)R410A
- Low Ambient (Cooling, ℃)0 ~ 50 ℃
- Low Ambient (Heating, ℃)-15 ~ 30 ℃
Flujo de aire
- Air Direction Control (Up/Down)Auto
- Air Direction Control (Left/Right)Manual
- Air Flow Control Step (Cool/Fan)4 / 4
Conveniencia
- SmartThingsNo
- AI Auto CoolingNo
- Motion Detect SensorNo
- Freeze WashNo
- Filter Cleaning IndicatiorNo
- Indoor Temp. DisplaySí
- Display On/OffSí
- Beep On/OffNo
- 24-Hour TimerSí
- Auto ChangeoverNo
- Auto RestartSí
Modo de operación
- Auto ModeSí
- Fast CoolSí
- Good SleepSí
- DehumidificationSí
- Fan ModeSí
- QuietNo
SAM-AR18BSHQAWK2BG
